Ray
ENGINE :Engine type Air-cooled, 4-stroke, SOHC, 2-valve Displacement
113 CC Bore & Stroke
50.0mm x 57.8mm Compression ratio
9.2:1 Maximum Horse Power
7.1PS /7,500 rpm Maximum torque 8.1 N.M / 5000 rpm Starting System Electric and Kick Lubrication Force-Feed Lubrication, Wet Sump Cylinder layout Single cylinder Clutch type Dry, centrifugal Ignition System CDI (Capacitor Discharge Ignition) Fuel supply Carburetor Battery 12 V, 5 AH(10 H) Headlight
Halogen Bulb 12V, 35W/35W x 1 Primary / Secondary Reduction Ratios 1.000/9.388 Transmission Type V-Belt Automatic
DIMENSIONS Overall (L x W x H) 1,815 mm x 675 mm x 1,120 mm Kerb Weight 103 kg Wheelbase 1,270 mm Minimum ground clearance
128 mm Engine Oil Volume 0.74L Fuel Tank Capacity 5.2L Seat height 775 mm
CHASSIS
Frame type
Underbone Front Suspension
Telescopic Rear Suspensions
Unit Swing Front Brake
Drum Brake Rear Brake
Drum Brake Front Tyre
90/100-10 53J (Tubeless) Rear Tyre
90/100-10 53J (Tubeless) Brake/Taillight
12V, 21W/5W x 1 Turn Signal Light (Front)
12V, 10W x 2 Turn Signal Light (Rear)
12V, 10W x 2
|
