Models | SILENT GE 3200DS |
Special Highlights | - Portable and light weight Diesel Genset
- Running cost is the lowest and very fuel Efficient , so produce electricity at very economical rates
- Run 0.75 ton Air Conditioners
|
Application | Very useful all-purpose portable genset for small electric loads up to 2.5 KVA also useful for running light machinery, motor and inductive loads like 0.75 Ton AC, Deep Freezer etc. |
Max AC. Output VA | 3000 |
Rated AC. Output VA | 2600 |
Rated Current Amps | 11.7 |
NFB Amps | 12 |
AC. Voltage On Laptop Mode | 230 Volts ± 10 Volts, 50 Hz, Single Phase |
AC. Voltage On Power Mode (No Load) | 250 Volts ± 5 Volts |
Alternator | #Alternator Max. Current Capacity | 24 Amps. |
Alternator | Brushless, Rare Earth Magnetic Rotor, THD = 2 %, Pure Sine Wave |
Engine | Model | TP170F |
Type | 4-Stroke, OHV, Single Cylinder, Direct Injection, Swirl Chamber, Inclined type |
Bore x Stroke | 70*54 mm |
Displacement | 208cc |
Starting System | Recoil Start and Self Start |
Fuel | Diesel |
Fuel Tank Capacity | 14.5 Ltrs. |
Fuel Consumption | 0.7 Ltr./hr. |
Lube. Oil Capacity | 700 ml. |
Lubricating Oil Consumption | 2.8 gm./Hr. |
Sound level (Db) | <75DB |
Panel & Other Standard Features | Voltmeter | Analogue |
Digital Hour Meter | No |
Oil Alert System | Yes |
Diesel Alert System | Yes |
Cooling Fan Indicator | Yes |
AMF Panel Auto & Remote Start Compatibility | No |
Fuel Level Gauge | Yes |
Overload Protection (NFB) | Yes |
Costar Wheels | Yes |
Gross weight-KG | 90 Kg. |
Packing | Dimension LxWxH (mm) | 1000x470x710 mm |
Battery Specification | 12 Volt 35 Ah Size =190×120×225 (L×W×H) |
Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specifications can change without any prior intimation |
